- Frequency range:
LPA 380: tune ... 380 430 MHz
- Impedance: 50% u03A9
- Radiation (H-plane): 360 ° omnidirectional
- Radiation (E-plane): beam @ -3 dB = 78 °
- Polarization: Linear Vertical
- Gain: 2 dBi (0 dB ref. U03BB% A / 4 whip) @ resonance frequency.
- Maximum Power (CW) @ 30 ° C: 100 watts
- Protection of land: all metal parts are DC-land, along the inner conductor is capacitively
- Cable Length / Type: 1 m / RG 58 C / U
- Connector: BNC male, another type of request
- Material: UV stabilized ABS, Aaluminium, Brass, Steel
- Dimensions (approx.): ?183mm, height 36mm
- Weight (approx.): 400 gr
- Operating Temperature: -40 ° C to 80 ° C
- Mounting Hole: 6x ?.5mm 2x ?6mm |
